400G-QSFP112
400G-LR4 QSFP112
400G-LR4 QSFP112 based on Silicon Photonics. 4 channels of 100G-PAM4 electrical and optical parallel lanes,duplex LC connector, 10km maximum reach via single mode fiber,case temperature range of 0℃-70℃, comply with IEE802.3ck and QSFP112 MSA standards, and support CMIS. Products are mainly used in 400G Ethernet, data centers and cloud networks.
400G-FR4 QSFP112
400G-FR4 QSFP112 based on Silicon Photonics. 4 channels of 100G-PAM4 electrical and optical parallel lanes,duplex LC connector, 2km maximum reach via single mode fiber,case temperature range of 0℃-70℃, comply with IEE802.3ck and QSFP112 MSA standards, and support CMIS. Products are mainly used in 400G Ethernet, data centers and cloud networks.
400G-DR4 QSFP112
400G-DR4 QSFP112 based on Silicon Photonics. 4 channels of 100G-PAM4 electrical and optical parallel lanes,Single optical port of MPO12, 500m maximum reach via single mode fiber,case temperature range of 0℃-70℃, comply with IEE802.3ck and QSFP112 MSA standards, and support CMIS. Products are mainly used in 400G Ethernet, data centers and cloud networks.
400G-DR4 QSFP112 LPO
400G-DR4 QSFP112 LPO based on Silicon Photonics.non-DSP design, 4 channels of 100G-PAM4 electrical and optical parallel lanes,Single optical port of MPO12, 500m maximum reach via single mode fiber,case temperature range of 0℃-70℃, comply with QSFP112 MSA standards, and support CMIS.
400G-VR4 QSFP112
400G-VR4 QSFP112 based on VCSEL. 4 channels of 100G-PAM4 electrical and optical parallel lanes,Single optical port of MPO12, 30m maximum reach via multimode fiber,case temperature range of 0℃-70℃, comply with IEE802.3ck and QSFP112 MSA standards, and support CMIS. Products are mainly used in 400G Ethernet, data centers and cloud networks.
400G-AOC QSFP112
Innolight's 400G QSFP112 AOC Series is based on silicon platform. These products feature four channels of 100G PAM4 electrical signals and four channels of 100G PAM4 optical signals, with a transmission distance of up to 100m over SMF. They have a case temperature range of 0℃-70℃ and comply with IEEE 802.3ck and QSFP112 MSA standards. The products are primarily used in 400G Ethernet, data centers, and cloud networks
